IPD Abutments
Offers a wide range of superior quality products & providing innovative solutions in the field of dental implants/prosthetics.
Complete restoration with Custom Interface System
The complete digital workflow for a unitary restoration & a bridge through the IPD scan abutment system & the Custom Interface System.
Scan Abutments
Accuracy, fit & reliability
One system, all solutions
Revolutionary high-precision Scan Abutment giving access to a fully integrated digital work flow.
A scan Abutment suitable for both intraoral & desktop scanning devices enabling to perform implant level frameworks as well as giving access to Custom Interface Ti-Base System or the one-of-a-kind high precision 3D printed models.
Scan Abutments Video
Revolutionary high precision Scan abutment that allows an integrated work system. With these Scan Abutments you will be able to work both in the clinic & in the laboratory & they will be used for direct implant & indirect implant restorations through the IPD Custom interface System.
Suitable for IO and Desktop scanning, IPD’ scan abutment offers the best performance in the market whilst allowing to use of Renishaw® tactile probe scan.
Our commitment with accuracy made us create a dedicated scan abutment to ensure matching the technical requirements of digital dentistry.
Starting with specific shapes for non-engaging and engaging abutments, as well as the two different abutment height on the engaging versions:
10mm for major cases and an extra of 15mm dedicated for deeper placements.
Making abutment always seating on the sagittal top of the implant or analogue jointly with our 5 microns manufacturing tolerances are making
possible to warranty the Z axis precision no matter the implant interface whilst the titanium manufactured interface ensures a long lasting and
accurate fitting as well allows to proceed checking the proper placing in mouth with X-Ray control. The use of the titanium Nitride coating (TiN),
aids on keeping a safe soft tissue thanks to its bacteriological properties. Deciding on PEEK for the abutment head which guarantees the best
possible performing in any scanning device meaning into an accurate implant placement into the CAD system.
Last but not least, its captive screw eases the use in the clinic while saves it to be falling apart and the reference code laser etching provides
a simple an easy way have everything under control.
Compatible Brand
Scan Transfers
Scan Transfer is an innovative scan abutment for the most demanding clinical cases such as All-on-4® & All-on-6®.
The abutment design, combined with our clinical/technical protocols, have been developed to allow splinting of the
scan abutments with a guide to assist in full arch scanning. Whilst performing a dual application for analog and
digital impressions, it is an essential tool to guarantee accuracy and repeatability.
This is a huge advantage when working digitally with the most complex and demanding dental implant treatment protocols
Technical Specifications
- Tapered design for easy axial scanning
- 5μm
- Assymetrical orientation cut-outs
- Maximized scanning area
- Retentive body that facilitates splinting
IPD Scan Transfer Digital Full-Arch Solution
This video shows the workflow for the scan transfer abutment.
Compatible Brand
Custom Interface Ti-Base System
Flexibility made Ti-Base
The most flexible & versatile Ti-Base on the market.
Choosing a suitable Ti-Base for each clinical case & restoration is essential for a long term success.
Get to know its innovative design
- Asymmetrical tri-lobe engaging design.
- Easier to mill geometry.
- Helical spiral grooves for improved retention.
- Larger surface area for the prosthetic restoration to avoid insufficient thickness depending on the materials used.
- 3 different Ti-Base platform: Narrow, Regular, & Wide. The emergence profile will accordingly grow from implant to prosthetic restoration.
- Adjustable height: With 8 mm as standard for the engaging versions & 6.5 mm for non-engaging.
- The recess for the Angled Screw Channel (ASC) can be adjusted for both engaging & non-engaging. Check availability according to implant system.
- CAD-CAM libraries are available for all possible variations.
- Different gingival heights for up to 3.5mm.
- Cutting guides with fixing screw facilitate cutting & trimming.
Engaging Interface
With a height of 8 mm, the engaging interface can be cut on several levels (6.5 mm / 5 mm / 3.5 mm), depending on each tasks requirements. Height adjustment is practical & simple using the cutting guides & fixation screw, making it possible to create the window for the angled screw channel for every available height from 6.5 mm.
Non-engaging Interface
With a height of 8 mm, the engaging interface can be cut on several levels (6.5 mm / 5 mm / 3.5 mm), depending on each tasks requirements. Height adjustment is practical & simple using the cutting guides & fixation screw, making it possible to create the window for the angled screw channel for every available height from 6.5 mm.
Discover our unique Custom Interface System
Discover the design & advantages of IPDs Custom Interface System: adjustment, precision & versatility. The most complete interface on the market.
Compatible Brand
Screws
With a height of 8 mm, the engaging interface can be cut on several levels (6.5 mm / 5 mm / 3.5 mm), depending on each tasks requirements. Height adjustment is practical & simple using the cutting guides & fixation screw, making it possible to create the window for the angled screw channel for every available height from 6.5 mm.
Material
Titanium Grade 5: TAl6V4 alloy. Biocompatible material with excellent mechanical properties.
Compatible Brand
Digital Analogs
Ensures the correct desire positions & maximize your workflow.
Digital Analog Video
Advantages of the digital analog with double fixing of IPD for high precision. Combined with the different tolerances (up to 10 different) from our 3D model library, you can generate models with an excellent fit.
The innovative design of our Digital Analog, with two fixation screws, ensures the exact positioning of the analog in a 3D printed model.
Its two fixation screws ensure that the analog is in the correct position, with one located on the side and the other at the bottom.
The side screw also enables the use of an articulator without losing the bite registration.
Temporary Abutments
The same abutment can be used as a temporary abutment with the occlusal screw or an impression coping using the coping screw.
Material
Titanium Grade 5: TAl6V4 alloy. Biocompatible material with excellent mechanical properties.
Compatible Brand
Healing Abutments
The healing abutments can be used to tighten & protect the gum tissues.
Material
Titanium Grade 5: TAl6V4 alloy. Biocompatible material with excellent mechanical properties.
Compatible Brand
Screw Drivers
Suitable for insertion of abutments.
Material
AISI 303: Stainless steel material with excellent mechanical properties.
RA Shanks
Ra Shank Ratchet
Length: 90 mm
Clinical Ra Shank Handle
Length: 90 mm
Laboratory Ra Shank Handle
Length: 90 mm
Screw Drivers
Hollow Screw Driver
Length: 90 mm
TPA Screw Driver
Length: 18 mm | 25 mm | 32 mm
Adapter
Ratchet Adapter
Length: n/a
Extractor Tool
PSD & Insert Extractor Tool
Length: n/a
PSD Overdenture System
System that will bring best quality to dental implants.
LOCATOR® Compatible
Small improvements make big differences.
Fully compatible with the Locator® system will bring you the chance to improve without changing.
The two PSD available retention set will be enabling to save up to 400 divergence levels between implants.
Each set will be including the relevant three retention level sleeves. The reduced coronal geometry of the
PSD anchor reduces the necessary vertical dimension improving not only aesthetics but prosthetic resistance.
TiN coating
The TiN coating improves periodontal aesthetics whilst reducing friction level getting into less wear for abutment and retention.
First digitalize overdenture system
IPD releases a one-of-kind solution enabling to digitalize PSD attachments. Nevertheless this item has also been designed to maximise
the benefit by supporting additional features such as impression coping or carrier.
Carrier
Thanks to its ergonomic design, this accessory allows to easily handle as well as aiding clinicians at chairside.
Impression Coping
Cutting the carrier just above the grooved shape will allow it to be used as an impression cap whereas it will also be possible to splint them if necessary.
Scan Body
By simply cutting on the blue line customer will get through a PSD Scan body supported by its relevant CAD libraries and even the very first 3D analogue
for overdenture attachments.
As always it is available for the major CAD systems in the market.
For more information about LOCATOR® - CLICK HERE
Driver Sets
Driver Sets for Dentists & Laboratories.
RA Shanks
Ra Shank Ratchet
Length: 90 mm
Clinical Ra Shank Handle
Length: 90 mm
Laboratory Ra Shank Handle
Length: 90 mm
Screw Drivers
Hollow Screw Driver
Length: 90 mm
TPA Screw Driver
Length: 18 mm | 25 mm | 32 mm
Adapter
Ratchet Adapter
Length: n/a
Extractor Tool
PSD & Insert Extractor Tool
Length: n/a
